The EFF-PRO comes with huge savings on space, product handling, utility cost, and process time. It provides excellent compressibility characteristics, leading to effervescent tablets with high physical stability and avoids breaking of the tablets during transportation.
Robust and reproducible granulation process, every time.
| EFF-PRO GRANULATION | REGULAR GRANULATION |
|---|---|
| Granulation, Drying and Blending all in One. | Need RMG, FBD equipment for complete process |
| Drying under vacuum at low/high temperatures | Drying with Hot air using fresh air, increases utility cost |
| Minimum product handling, machine itself maintain the humidity & temperature of product | Product to be handled at various stages, increases chances of losing its properties |
| Less Space required | More Space required |
| Aqueous based coating helps for quick process. | IPA based coating solution is mandatory |
| No need of Flameproof area, as no IPA used | Need complete Flameproof arrangement with machine and area. |
| Process time required 3 to 3 Hr only | Process time required 3 to 3 Hr only |
| Manufacturing takes place at 30% relative Humidity condition | Relative Humidity required below 20% |
| Tablets processed in EFF-PRO Granulation dissolves faster | Tablets dissolving time will be depending upon drying process. |
| DESCRIPTION | MACHINE DATA-EFF PRO RANGE | |||
|---|---|---|---|---|
| Production range | EFF-PRO 25 | EFF-PRO 50 | EFF-PRO 100 | EFF-PRO 250 |
| Batch Size | 25kg | 50kg | 100kg | 250kg |
| Foot Print in Area | 2mtr x 1mtr | 2.5mtr x 2mtr | 4mtr x 3mtr | 5.5mtr x 3mtr |
| Foot Print in Utility | 3mtr x 3mtr | 3mtr x 3mtr | 4mtr x 4mtr | 4mtr x 4mtr |
| Vacuum Pump | 3HP | 3HP | 5HP | 7.5HP |
| Machine weight | 500kg | 750kg | 1000kg | 1400kg |
| Connecting Load | 7.5KW | 15KW | 25KW | 35KW |
